Representative Coordination Scopes · Vancouver, BC

Selected Projects

CommercialInstitutionalMid-Rise Residential

Representative coordination scopes for rainscreen cladding and building-envelope work. These anonymous archetypes illustrate service categories; they are not named customer case studies or proof that every listed condition was delivered by FPG.

Project Archetypes

Project Archetypes

K–12 Education

Multi-System School Re-Clad

Composite metal panel, phenolic and corrugated metal across a school envelope with curtain-wall interfaces. Phased to keep the school occupied through construction.

ACMPhenolicCorrugated
Institutional · Healthcare

Full Envelope Mid-Rise

Fibre cement rainscreen over fluid-applied AVB, with thermally-broken sub-frame and acoustic detailing at envelope-to-mechanical transitions.

Fibre CementFluid AVB
Commercial Podium

Terracotta & ACM Mixed Facade

Extruded terracotta on tower above a composite metal podium. Mast-climber access. Concealed-fix terracotta and cassette-style ACM with route-and-return corners.

TerracottaACMMast-climber
Mid-Rise Residential

Fibre Cement Rainscreen

Equitone fibre cement with concealed-fix detail on a 6-storey wood-frame podium. Swing-stage access, self-adhered AVB tied into window flashings.

EquitoneSA AVBSwing-stage
Civic · Government

Swisspearl Concealed-Fix

Fully concealed-fix Swisspearl on a civic building. Full-height parapet returns, soffit transitions and articulated bays. Design-assist from DD through CD.

SwisspearlDesign-AssistConcealed-Fix
Envelope Remediation

Single-Elevation Re-Clad

Occupied-building re-clad coordination for a single elevation, including existing-cladding removal, AVB interfaces, new rainscreen and sequencing around occupancy constraints.

Re-cladOccupied

How a Project Moves Through Our Shop

  1. Design-assist or hard-bid intake

    FPG reviews the available documents, system interfaces, scope assumptions and estimating inputs, then confirms a project-specific response timeline.

  2. Shop drawings & mock-up

    Shop drawings are prepared for project-team review. Engineering, professional sealing and mock-up requirements are separately identified and coordinated with qualified parties when the project requires them.

  3. Production & install

    FPG manages qualified project subcontractors and coordinates field questions, RFIs, progress records and the closeout items defined in the project scope.

Closeout requirements are confirmed for each project and may include deficiency records, progress documentation, approved revisions and applicable warranty documents.
Looking for a Specific Reference?

Looking for a Specific Reference?

For procurement and pre-qualification requests, contact info@figphilpsgroup.ca. FPG will confirm which project information and references may be shared under the applicable customer authorizations.


Send drawings, get a recommendation

Send the available drawings and schedule. FPG will confirm document completeness, scope questions and the expected response timeline.
